Specifications
|
|
Model
|
TTH2560
|
TTH50100H
|
TTH3060E |
|
Lifting capacity (max)
|
2500kg
|
5000kg
|
3000kg |
|
Lifting height(max)
|
6000mm
|
10000mm
|
6000mm |
|
Forward reach(max)
|
3280mm
|
68400mm
|
3297mm |
|
Overall weight
|
8000kg
|
12500kg
|
8300kg |
|
Transmission
|
Hydro-mechanical transmission
|
Hydro-static transmission
|
Hydro-mechanical transmission
|
|
Drive type
|
Four wheel drive
|
Front wheel drive |
|
Control method
|
Integrated control handle
|
|
Boom Segments
|
2 sections
|
3 sections
|
2 sections
|
|
Dimensions
|
|
Overall length
|
6227mm
|
7910mm
|
5795mm |
|
Overall width
|
2400mm
|
2450mm
|
2300mm |
|
Overall height
|
2300mm
|
2690mm
|
2587mm |
|
Wheel base
|
3000mm
|
3100mm
|
2725mm |
|
Tread
|
2050mm
|
2005mm
|
1890mm |
|
Ground Clearance(min)
|
310mm
|
450mm
|
310mm |
|
Productivity
|
|
Lifting capacity at maximum height
|
2500kg
|
3000kg
|
2000kg |
|
Lifting capacity at maximum at reach
|
1000kg
|
800kg
|
1000kg |
|
Travel speed
|
25km/h(2 forward,2 reverse)
|
28km/h(4 forward,4 reverse)
|
25km/h(2 forward,2 reverse) |
|
Boom angle range
|
-14 degree --- 58 degree
|
-5 degree --- 61 degree
|
-18 degree --- 54 degree |
|
Driving/steering models
|
4 wheel drive rear,4 wheeling steering
|
4 wheel drive,rear wheel steering
|
front wheel drive,rear wheeling steering |
|
Outside turning radius (4 wheel steering)
|
7015mm
|
7263mm
|
/ |
|
Inside turning radius (4 wheel steering)
|
/ |
2090mm |
|
Color
|
Violet(painting)
|
|
Power
|
|
Engine
|
Cummins
|
Yituo Dongfanghong |
|
Model
|
4BT3.9-C80
|
4BT3.9-C125
|
/ |
|
Rated power
|
82HP/60kw
|
126HP/93kw
|
82HP/60kw |
|
Fuel tank capacity
|
140L
|
150L
|
140L |
|
Hydraulic oil tank capacity
|
110L
|
165L
|
110L |
| Note: All specifications on our web-site are subject to technical modifications without notice. |
