TB Series Electric Pallet Stacker

Product name : TB Series Electric Pallet Stacker

Item : TB10-16/10-25/10-30/10-35/15-25/15-30/20-16

Details :

1. It is suitable for Single face pallet.

2. Max lifting height is 4500mm. Standard vibration damper pedal and Skidproof mat.

3. Multifunctional operating handle, standard emergency power-off switch, electric

quantity display.

4. Optional configuration: AC driving motor,FAAM battery,arm rest.

Specifications
Description	Electric Pallet Stacker
Model	TB10-16	TB10-25	TB10-30	TB10-35	TB15-25	TB15-30	TB20-16
Load capacity	1000kg	1000kg	1000kg	1000kg	1500kg	1500kg	2000kg
Max. lifting height	1600mm	2500mm	3000mm	3500mm	2500mm	3000mm	1600mm
Overall length	2023mm	2023mm	2023mm	2023mm	2023mm	2023mm	2023mm
Overall width	850mm	850mm	850mm	850mm	850mm	850mm	850mm
Overall height mast closed	2080mm	1795mm	2045mm	2295mm	1795mm	2040mm	2080mm
Min. intersecting aisle	2450mm	2450mm	2450mm	2450mm	2450mm	2450mm	2450mm
Total weight (with battery)	880kg	935kg	950kg	975kg	940kg	950kg	905kg
